Vishay Intertechnology Expands Power Transformer Portfolio With New IFBT Series for Flyback Converter Topologies

· Issued by Vishay Intertechnology, Inc. via GlobeNewswire
Watch Vishay Intertechnology explain itVishay Intertechnology, Inc. (VSH) Q2 2026 Earnings Call · Replay · Aug 5

Customizable Flyback Transformers Support Wide 26 V to 72 V Input Range and High Isolation of 1500 VRMS for 60 s

MALVERN, Pa., Aug. 27, 2026 (GLOBE NEWSWIRE) -- Vishay Intertechnology, Inc. (NYSE: VSH) today announced that it has expanded its power transformer line with a new series designed for flyback converter topologies. Featuring 17 devices, the Vishay Dale IFBT series of customizable, surface-mount flyback transformers is designed to operate with a wide 26 V to 72 V input voltage range at 250 kHz while providing high isolation of 1500 VRMS for 60 s from primary and bias windings to secondary.

The devices released today feature multiple windings, allowing for combinations of series and parallel connections to support different voltage and current handling configurations. Along with their wide input voltage range, this flexibility enables output voltages from 1.8 V to 24 V and output currents from 0.5 A to 9.0 A. The RoHS-compliant transformers offer inductance values from 35.0 µH to 75.0 µH and operate over a temperature range of -40 °C to +125 °C.

IFBT series devices will serve as flyback transformers for 6 W and 30 W PoE designs, as well as isolated DC/DC converters up to 30 W. Typical applications will include automotive lighting LED driver transformers; energy generation, distribution, and management systems; industrial drives, tools, and automation systems; home and building controls; consumer devices; white goods; telecom equipment; and medical instrumentation. For these use cases, the devices' open construction allows for easy modification of the windings to meet specific customer requirements.

Device Specification Table:

Part #

Ind. ± 10 % (µH)

LK ind. (µH).

DCR max. (Ω)

Turns ratio

Ipk max. (A)

Output
(V / A)

Pri

Sec

Bias

Pri:sec

Pri:bias / aux

IFBT0709ZIFS061R80

75.0

8.40

0.195

0.005

0.195

1:0.07

1:0.36

1.3

1.8 / 3.3

IFBT0709ZIFS062R50

55.0

4.80

0.095

0.005

0.150

1:0.08

1:0.33

1.2

2.5 / 2.4

IFBT0709ZIFS063R30

65.0

4.00

0.138

0.007

0.180

1:0.11

1:0.36

1.2

3.3 / 1.8

IFBT0709ZIFS065R00

60.0

2.45

0.130

0.009

0.165

1:0.15

1:0.36

1.1

5.0 / 1.2

IFBT0709ZIFS061200

50.0

0.76

0.095

0.017

0.150

1:0.15

1:0.35

1.1

12 / 0.5

IFBT0709ZIFS131R80

45.0

8.00

0.195

0.005

0.195

1:0.07

1:0.36

2.3

1.8 / 7.2

IFBT0709ZIFS132R50

35.0

4.40

0.095

0.005

0.150

1:0.08

1:0.33

2.2

2.5 / 5.2

IFBT0709ZIFS133R30

40.0

3.50

0.138

0.007

0.180

1:0.11

1:0.36

2.2

3.3 / 3.9

IFBT0709ZIFS135R00

40.0

2.00

0.130

0.009

0.165

1:0.15

1:0.35

2.1

5.0 / 2.6

IFBT0709ZIFS131200

35.0

0.65

0.095

0.017

0.150

1:0.35

1:0.35

2.0

12 / 1.1

IFBT0709ZIFS132000

37.0

0.43

0.085

0.025

0.150

1:0.57

1:0.35

2.0

19.5 / 0.67

IFBT0709ZIFS132400

37.0

0.43

0.086

0.049

0.150

1:0.57

1:0.33

2.0

24 / 0.54

IFBT0912ABFS303R30

42.0

3.15

0.072

0.003

0.235

1:0.09

1:0.33

2.6

3.3 / 9.0

IFBT0912ABFS305R00

42.0

1.70

0.071

0.006

0.240

1:0.14

1:0.33

2.6

5.0 / 6.0

IFBT0912ABFS301200

42.0

0.56

0.063

0.017

0.205

1:0.33

1:0.33

2.6

12 / 2.5

IFBT0912ABFS302000

42.0

0.44

0.062

0.038

0.205

1:0.56

1:0.33

2.6

19.5 / 1.5

IFBT0912ABFS302400

42.0

0.33

0.062

0.057

0.205

1:0.67

1:0.33

2.6

24 / 1.25

Samples and production quantities of the IFBT series are available now, with lead times of 10 to 12 weeks.
