Applied Materials Introduces New Systems to Accelerate DRAM and Advanced Packaging for AI Chips
Innovations spanning DRAM and advanced packaging enable the 3D architectures behind cutting-edge AI chipsA new epitaxy system optimized for DRAM fabs adds a critical logic-class step—boosting memory speed and efficiency while maximizing output within tight fab footprint and supply constraints New CMP and deposition systems target the most critical advanced packaging steps, delivering higher-yield chip stacking for HBM and logicNew eBeam systems bring wafer-fab-grade metrology and defect review t
About this update from Applied Materials, Inc.
SANTA CLARA, Calif., June 25, 2026 (GLOBE NEWSWIRE) -- Applied Materials, Inc., the leader in materials engineering for the semiconductor industry, today introduced a suite of new chipmaking systems for building the advanced 3D chip architectures that power next-generation AI. AI compute is increasingly constrained by memory, as model scale and data movement demands outpace gains in bandwidth, capacity and energy efficiency. This growing "memory wall" is accelerating adoption of advanced packaging architectures, including high bandwidth memory (HBM) and 3D stacking. These technologies deliver step-change improvements in bandwidth and efficiency but introduce new challenges in process complexity. Applied is enabling this transition with a materials engineering portfolio spanning DRAM, advanced packaging and process control, extending its leadership across each domain to help customers bring a new generation of AI chips to production faster and at higher yield. Enhanced Epitaxy Brings Logic-Class Technology to Next-Generation DRAM Epitaxy has been used for years in leading-edge logic, where precision growth of a crystalline material in the transistor channel has boosted performance well beyond what geometric scaling alone can deliver. Those same techniques are now becoming critical in DRAM peripheral transistors. Applied pioneered silicon germanium epitaxy in transistor channels more than a decade ago with its Centura™ Prime™ Epi system. Enhanced Centura™ Prime™ Epi Applied is now introducing an enhanced Centura™ Prime™ Epi system that selectively grows doped silicon germanium and silicon phosphorous in source/drain regions, combining advanced strain engineering with precise doping control. The result is higher drive current and transistor efficiency, enabling faster, more power-efficient DRAM operation—essential for the bandwidth demands of HBM and next-generation DDR. The new system also features a 20% smaller footprint, enabling higher tool density and faster capacity scaling in DRAM fabs.
